AA®100 HI Curtain Wall System

Introduction

Our market-leading stick-frame assembly featuring Passive House performance criteria with additional weather performance achieved by drainage and ventilation of the glazing rebates. Drainage and ventilation occurs at every mullion and transom connection in a zone drained system and at the base and above mullion joints in a mullion drained system.

The system is available in a variety of mullion depths which combined with several thermal break options and aesthetic external capping allows a specifier the flexibility of design to make their own statement. The system has outstanding performance and its ease of installation makes it possible to suit individual project requirements.

Please see the below to assist with choosing the right system for your project:
Zone or Mullion Drained?

Design Considerations
A comprehensive range of mullions and transoms allow façades to be designed with minimal structural support.

The selection of mullion is dependent on several factors:

• The span (the distance between the fixings to supporting structure)
• The mullion centres (up to 3.0m using AA®100 curtain walling)*
• Windload (up to 2400 Pa)
• Maximum weight of infill (up to 700kg)
• The deflection limitations of the glazing system
• The drainage method required; i.e. zone or mullion

Guidance on this element of the curtain wall design should be sought from the Kawneer Architectural Services Team.

_{* For mullion centres greater than 3.0m contact the Technical Services Team at Runcorn.}

Product Features and Benefits

• Concealed zone drainage  – each pane acts as an individual self-draining unit or mullion drainage – ventilation and drainage via the mullions
• Glazing up to 60mm

• Large choice of face caps to enable total design flexibility to suit your individual aesthetic requirements
• Bespoke face caps available (subject to approval)
• Patented transom overlap detail which gives the uniform aesthetic finish
• Market leading product tested and certified in accordance with CWCT Sequence B
• Range of mullion, transom and face cap options with 50mm sightlines
• Enhanced thermal performance to meet or exceed current Building Regulations
• Passive House certified solution available
• Incorporates AA®130 Brise Soleil System
• Facilitates the integration of opening window products including a concealed vent option

_{Contact our Technical Services Team at Runcorn regarding specific infill options for Passive House.}

Project Assistance

For advice and support and to ensure you find the best solution for your individual project needs, please contact our Architectural Services Team.
