U value TGU
0.76 W/m²K
U value DGU
1.1 W/m²K
Windload
Class C5
Air Permeability
Class 4
Watertightness
Class 9A
Glazing weight
130kg
Security
EN 1627 RC2, PAS24
Acoustics
C;Ctr = 40 (-1, -3) dB
Certification
Passive House
Maximum size
2835mm
Frame width
24mm – 64mm
System depth
92mm
Minimum Sightline
88mm
Glazing thickness
24mm – 65mm
Glazing type
Double, Triple
Drainage and ventilation
Yes
Multi-point locking
Yes
Restrictor
Yes (Document M)
Open options
Open in
Concealed vent
Yes
Finishes
130+
Top hung
No
Side hung
Yes (130kg)
2 stage opening
Yes (130kg)
Bottom hung
Yes (80kg)
TBT
Yes (130kg – 180kg)
Turn-Tilt
Yes (130kg – 180kg)
French casement
Yes (130kg)
Parallel opening
No
Fixed Light
Yes (300kg)
Horizontal pivot
No
Vertical pivot
No
Barrier Load
Yes
Impact resistance
Class 5
Line load
1.50 kN/m
Point load
0.50 kN/m
Certification
BS6180, BS EN13049
Leaf design
Single or double
Min width
Single 650mm
Max width
Double 2x 1000mm
Top handrail height
1100mm
Finishes
130+
Barrier Load
Yes
Impact resistance
Class 5
Line load
0.74 kN/m
Point load
0.50 kN/m
Certification
BS6180, BS EN13049
Leaf design
Single or double
Min width
Single 650mm
Max width
Double 2x 1000mm
Top handrail height
1100mm – 1500mm
Finishes
130+
Curtain wall integration
Yes
Glazing
10mm – 18mm
U value TGU
0.76 W/m²K
U value DGU
1.1 W/m²K
Windload
Class C5
Air Permeability
Class 4
Watertightness
Class 9A
Glazing weight
300kg
Security
EN 1627 RC2, PAS24
Acoustics
C;Ctr = 40 (-1, -3) dB
Certification
Passive House
Maximum size
2800mm
Frame width
24mm – 64mm
System depth
92mm
Miniumum sightline
52mm
Glazing thickness
24mm – 65mm
Glazing type
Double, Triple
Drainage and ventilation
Yes
Multi-point locking
Yes
Restrictor
Yes (Document M)
Open options
Open in
Concealed vent
Yes
Finishes
130+
Top hung
No
Side hung
Yes (130kg)
2 stage opening
Yes (130kg)
Bottom hung
Yes (80kg)
TBT
Yes (130kg – 180kg)
Turn-Tilt
Yes (130kg – 180kg)
French casement
Yes (130kg)
Parallel opening
No
Fixed Light
Yes (300kg)
Horizontal pivot
No
Vertical pivot
No
Uf value
≤0.8 W/m²K
Windload
2400Pa
Air Permeability
600Pa
Watertightness
600Pa
Infill weight
700KG
Acoustics
C;Ctr = 48 (-2, -6) dB
Certification
Passive House, CWCT Sequence B
System width
50mm
System depth
65mm – 275mm
Glazing thickness
6mm – 60mm
System movement
+/- 2mm
Barrier Load
Yes
Drainage
Concealed zone or mullion
Capping
Full, horizontal, vertical
Vent options
Concealed, open in, open out
Blast Mitigated
No
SSG available
No
Finishes
130+
U value
DGU 1.0 | TGU 0.5
Windload
Class AE2400
Air Permeability
Class 4
Watertightness
Class 9A
Glazing weight
300kg
Security
PAS24
Acoustics
C;Ctr = 41 (-2, -6) dB
Certification
Maximum size
2400mm
Frame width
24mm – 64mm
System depth
72mm – 160mm
Minimum sightline
24mm
Glazing thickness
22mm – 60mm
Glazing type
Double, Triple
Drainage and ventilation
Yes
Multi-point locking
Yes
Restrictor
100mm
Open options
Open out, open in
Finishes
130+
Top hung
No
Side hung
Yes (130kg)
2 stage opening
No
Bottom Hung
Yes (50kg)
TBT
Yes (130kg)
Turn-Tilt
Yes (130kg)
French casement
Yes (130kg)
Parallel opening
No
Fixed Light
Yes (300kg)
Horizontal pivot
No
Vertical pivot
No
Uf value
2.36 W/m²K
Windload
2400Pa
Air Permeability
600Pa
Watertightness
600Pa
Infill weight
600KG
Acoustics
C;Ctr = 48 (-2, -6) dB | Flanking 41db to 57db DnFw
Certification
CWCT Sequence B
System width
65mm
System depth
65mm – 275mm
Glazing thickness
2mm – 50mm
System movement
+/- 15mm
Barrier Load
Yes
Drainage
Concealed zone or mullion
Capping
Full, horizontal, vertical
Vent options
Concealed, open in, open out
Blast Mitigated
No
SSG available
Yes
Finishes
130+
Uf value
0.83 W/m²K
Windload
2400Pa
Air Permeability
600Pa
Watertightness
600Pa
Infill weight
700kg
Acoustics
C;Ctr = 45 (-2, -6) dB
Certification
CWCT Sequence B
System width
65mm
System depth
65mm – 275mm
Glazing thickness
4mm – 58mm
System movement
+/- 5mm
Barrier Load
Yes
Drainage
Mullion
Capping
Head only or perimeter
Vent options
Concealed, open in, open out
Blast Mitigated
No
Capped available
Yes
Finishes
130+
Security
RC2
Windload
2000Pa
Air Permeability
600Pa
Watertightness
E750
Impact Resistance
E5
Certification
CWCT Sequence B
System compatibility
AA100, AA110, SSG
Glazing thickness
30mm – 50mm
Glazing type
Double, Triple
Infill weight
180KG
Maximum size
3000mm
Minimum size
400mm
Restrictor
Yes (Document M)
Opening operation
Manual or motorised
Finishes
130+
Top hung
Yes
Parallel
Yes
Side hung
No
Bottom hung
No
U value
1,4 – 2,0 W/m²K
Windload
Class AE2400
Air Permeability
Class 4
Watertightness
Class 7A
Glazing weight
300kg
Security
PAS 24
Acoustics
C;Ctr = 39 (-2, -5) dB
Certification
Passive House
Maximum size
2500mm
Frame width
24mm – 64mm
System depth
72mm
Minimum sightline
23mm
Glazing thickness
22mm – 60mm
Glazing type
Double, Triple
Drainage and ventilation
Yes
Multi-point locking
Yes
Restrictor
Yes (Document M)
Open options
Open out
Finishes
130+
Top hung
Yes (130kg)
Side hung
Yes (52kg)
2 stage opening
No
Bottom hung
No
TBT
No
Turn-Tilt
No
French casement
No
Parallel opening
No
Fixed Light
Yes (300kg)
Horizontal pivot
No
Vertical pivot
No
U value
1,4 – 2,0 W/m²K
Windload
Class AE2400
Air Permeability
Class 4
Watertightness
Class 7A
Glazing weight
300KG
Security
PAS 24
Acoustics
C;Ctr = 40 (-6) dB
Certification
Passive House
Maximum size
1500mm
Frame width
23mm – 52mm
System depth
72mm
Minimum sightline
23mm
Glazing thickness
22mm – 60mm
Glazing type
Double, Triple
Drainage and ventilation
Yes
Multi-point locking
No
Restrictor
100mm
Open options
Open out, open in
Flush casement
Yes
Finishes
130+
Top hung
Yes (50kg)
Side hung
Yes (26kg – 40kg)
2 stage opening
No
Bottom hung
No
TBT
No
Turn-Tilt
No
French casement
No
Parallel opening
No
Fixed Light
Yes (300kg)
Horizontal pivot
No
Vertical pivot
No
U value
1,4 – 2,0 W/m²K
Windload
Class AE2400
Air Permeability
Class 4
Watertightness
Class 7A
Glazing weight
300kg
Security
PAS 24
Acoustics
C;Ctr = 39 (-2, -5) dB
Certification
Passive House
Maximum size
1900mm
Frame width
24mm-64mm
System depth
72mm
Minimum sightline
23mm
Glazing thickness
22mm – 60mm
Glazing type
Double, Triple
Drainage and ventilation
Yes
Multi-point locking
Yes
Restrictor
100mm
Open options
Open out, open in
Finishes
130+
Top hung
No
Side hung
No
2 stage opening
No
Bottom hung
No
TBT
No
Turn-Tilt
No
French casement
No
Parallel opening
No
Fixed Light
Yes (300kg)
Horizontal pivot
Yes (150kg)
Vertical pivot
Yes (110kg)
U value
1,4 – 2,0 W/m²K
Windload
Class AE2400
Air Permeability
Class 4
Watertightness
Class 7A
Glazing weight
300kg
Security
PAS 24
Acoustics
C;Ctr = 39 (-2, -5) dB
Certification
Passive House
Maximum size
2500mm
Frame width
24mm – 64mm
System depth
72mm
Minimum sightline
23mm
Glazing thickness
22mm – 60mm
Glazing type
Double, Triple
Drainage and ventilation
Yes
Multi-point locking
Yes
Restrictor
100mm
Open options
Open out, open in
Finishes
130+
Top hung
No
Side hung
No
2 stage opening
No
Bottom hung
No
TBT
No
Turn-Tilt
No
French casement
No
Parallel opening
Yes (200kg)
Fixed Light
Yes (300kg)
Horizontal pivot
No
Vertical pivot
No
U value
1,4 – 2,0 W/m²K
Windload
Class AE2400
Air Permeability
Class 4
Watertightness
Class 7A
Glazing weight
300KG
Security
PAS 24
Acoustics
C;Ctr = 47 (-1, -3) dB
Certification
Passive House
Maximum size
2500mm
Frame width
24mm – 64mm
System depth
72mm
Minimum sightline
23mm
Glazing thickness
22mm – 60mm
Glazing type
Double, Triple
Drainage and ventilation
Yes
Multi-point locking
Yes
Restrictor
100mm
Open options
Open out, open in
Finishes
130+
Top hung
No
Side hung
Yes (130kg – 200kg)
2 stage opening
No
Bottom hung
Yes (50kg)
TBT
Yes (130kg – 200kg)
Turn-Tilt
Yes (130kg – 200kg)
French casement
Yes (130kg)
Parallel opening
No
Fixed Light
Yes (300kg)
Horizontal pivot
No
Vertical pivot
No
U value
1,4 – 2,0 W/m²K
Windload
Class AE2400
Air Permeability
Class 4
Watertightness
Class 7A
Glazing weight
300kg
Security
PAS 24
Acoustics
C;Ctr = 47 (-1, -3) dB
Certification
Passive House
Maximum size
2500mm
Frame width
24mm – 64mm
System depth
72mm
Minimum sightline
23mm
Glazing thickness
22mm – 60mm
Glazing type
Double, Triple
Drainage and ventilation
Yes
Multi-point locking
Yes
Restrictor
100mm
Open options
Open out, open in
Finishes
130+
Top hung
No
Side hung
Yes (130kg – 200kg)
2 stage opening
Yes (80kg)
Bottom hung
No
TBT
No
Turn-Tilt
No
French casement
No
Parallel opening
No
Fixed Light
Yes (300kg)
Horizontal pivot
No
Vertical pivot
No
Uf value
0.93 W/m²K
Windload
2400Pa
Air Permeability
600Pa
Watertightness
600Pa
Infill weight
700KG
Acoustics
C;Ctr = 48 (-2, -6) dB
Certification
CWCT Sequence B
System width
50mm
System depth
65mm – 275mm
Glazing thickness
4mm – 58mm
System movement
+/- 2.5mm
Barrier Load
Yes
Drainage
Mullion
Capping
Head only or perimeter
Vent options
Concealed, open in, open out
Blast Mitigated
No
Capped available
Yes
Finishes
130+
Uf value
1.93 W/m²K
Windload
2400Pa
Air Permeability
600Pa
Watertightness
600Pa
Infill weight
600KG
Acoustics
C;Ctr = 48 (-2, -6) dB | Flanking 41db – 57dB DnFw
Certification
CWCT Sequence B
System width
50mm
System depth
65mm – 275mm
Glazing thickness
4mm – 50mm
System movement
+/- 2mm
Barrier Load
Yes
Drainage
Concealed zone or mullion
Capping
Full, horizontal, vertical
Vent options
Concealed, open in, open out
Blast Mitigated
No
SSG available
Yes
Finishes
130+
